Super runway sawing and milling workstation + double-head end milling + robot + sorting line + complete set of vehicles

Equipment advantages ◎The new "central brain" (five channels of the family system) through the overall context, experience more wisdom! ◎Independent five-channel-mutual independent processing zone, avoid interference, more collabo- rative work more efficient! ◎Runway type laser cutting device--longer travel, corner code hole glue hole process without time! ◎Intelligent manipulator: automatic error correction function, clip induction, automatic rotation, intelligent memory! ◎On the saw blade any Angle cutting- can cut any Angle and Angle, to meet a variety of processing needs! ◎Independent Angle cutting device-equipped with independent tail knife Angle cutting device, more than fast! The King of Speed MC super pro MAICHEN CNC P 03-04 Advantage: ◎Cooperate with the host equipment to realize material transmission between processing equipment, reduce handling time and labor intensity, and improve production efficiency. ◎ Equipped with variable frequency transmission motor, the speed variable frequency is adjustable, and can be adjusted according to the production process rhythm ◎ Release a section at an interval of 15 seconds according to the profiles equipped with the sawing center. ◎ Single section length 4000mm-6000mm, adjust according to actual needs. ◎The maximum length of the sorting profile is 5000mm and the maximum width is 200mm (customizable). ◎ Equipped with transmission roller line and horizontal conveyor belt, the horizontal conveyor belt can be raised and lowered as needed. ◎ Equipped with industrial scanner for sorting flow direction control according to process requirements. ◎The roller diameter is 50mm, the rubber thickness is 3mm, the rubber center distance is 120mm, the single motor power is 0.75KW, and the load is 30KG.

Key words:

Classification:

Aluminum Alloy Door and Window Equipment

Service Hotline:

400-1669-567

Product inquiry

Related Products

Product description

Equipment advantages ◎The new "central brain" (five channels of the family system) through the overall context, experience more wisdom! ◎Independent five-channel-mutual independent processing zone, avoid interference, more collabo- rative work more efficient! ◎Runway type laser cutting device--longer travel, corner code hole glue hole process without time! ◎Intelligent manipulator: automatic error correction function, clip induction, automatic rotation, intelligent memory! ◎On the saw blade any Angle cutting- can cut any Angle and Angle, to meet a variety of processing needs! ◎Independent Angle cutting device-equipped with independent tail knife Angle cutting device, more than fast!
The King of Speed MC super pro MAICHEN CNC P 03-04

Advantage: ◎Cooperate with the host equipment to realize material transmission between processing equipment, reduce handling time and labor intensity, and improve production efficiency. ◎ Equipped with variable frequency transmission motor, the speed variable frequency is adjustable, and can be adjusted according to the production process rhythm ◎ Release a section at an interval of 15 seconds according to the profiles equipped with the sawing center. ◎ Single section length 4000mm-6000mm, adjust according to actual needs. ◎The maximum length of the sorting profile is 5000mm and the maximum width is 200mm (customizable). ◎ Equipped with transmission roller line and horizontal conveyor belt, the horizontal conveyor belt can be raised and lowered as needed. ◎ Equipped with industrial scanner for sorting flow direction control according to process requirements. ◎The roller diameter is 50mm, the rubber thickness is 3mm, the rubber center distance is 120mm, the single motor power is 0.75KW, and the load is 30KG.
